Hilf mir, TYPO3 Upgrade Wizard! Gridelements-Datensätze sauber migrieren.

Aufgaben:

• Alle betroffenen Elemente auswählen und deren CType entsprechend ändern
• Neue Inline-Elemente für die bisherigen Gridelements-Kindelemente erstellen und bestehende Inhalte dahin migrieren
• Falls vorhanden, FAL-Relationen in der Tabelle “sys_file_reference” mit dem neuen Inline-Element verknüpfen
• Alte Datensätze löschen

ext_localconf.php:

$GLOBALS['TYPO3_CONF_VARS']['SC_OPTIONS']['ext/install']['update']['tabs']
    = \MyProject\Sitepackage\Updates\MigrateTabs::class;

Classes/Updates/MigrateTabs.php:

<?php

namespace MyProject\Sitepackage\Updates;

use Exception;
use InvalidArgumentException;
use RuntimeException;
use TYPO3\CMS\Core\Database\ConnectionPool;
use TYPO3\CMS\Core\Database\Query\QueryBuilder;
use TYPO3\CMS\Core\Database\Query\Restriction\DeletedRestriction;
use TYPO3\CMS\Core\Utility\GeneralUtility;
use TYPO3\CMS\Install\Updates\UpgradeWizardInterface;

/**
 * Migrates existing "Tab Container" content elements to CType "tab".
 * In TYPO3 v8, the website contains a gridelements container with layout "Tab Container".
 * The contents of this container have to be migrated to use the CType "tab" for bootstrap package tabs.
 * "Tab Container" content elements are restricted to colPos "0" in all backend layouts.
 *
 */

class MigrateTabs implements UpgradeWizardInterface
{
    /**
     * @var int
     */
    protected int $gridElementBELayout = 14;

    /**
     * @var string
     */
    protected string $tableTab = 'tt_content';

    /**
     * @var string
     */
    protected string $targetTableTabItem = 'tx_bootstrappackage_tab_item';

    /**
     * @var string
     */
    protected string $targetCTypeTab = 'tab';

    /**
     * @var int
     */
    protected int $colPos = 0;

    /**
     * @var string
     */
    protected string $sourceFieldNameImage = 'image';

    /**
     * @var string
     */
    protected string $targetFieldNameImage = 'media';


    /**
     * Return the identifier for this wizard
     * This should be the same string as used in the ext_localconf class registration
     *
     * @return string
     */
    public function getIdentifier(): string
    {
        return 'tabs';
    }

    /**
     * Return the speaking name of this wizard
     *
     * @return string
     */
    public function getTitle(): string
    {
        return 'Tabs: Migrate existing tabs with Grid Layout "Tab Container"';
    }

    /**
     * Return the description for this wizard
     *
     * @return string
     */
    public function getDescription(): string
    {
        return 'Migrate existing tabs with Grid Layout "Tab Container"';
    }

    /**
     * Execute the update
     *
     * Called when a wizard reports that an update is necessary
     *
     * @return bool Whether everything went smoothly or not
     */
    public function executeUpdate(): bool
    {
        $this->migrateTabs();
        return true;
    }

    /**
     * Migrate existing content elements to new CType "tab".
     * 1. Get all gridelements containers with Grid Layout "Tab Container" and change their CType to "tab".
     * 2. Add a new content element for each of the container's children.
     * 3. Migrate the fields "header", "bodytext" and "image" to the fields in the new elements:
     *    "header", "bodytext" and "media"
     */
    protected function migrateTabs()
    {
        $connection = GeneralUtility::makeInstance(ConnectionPool::class)->getConnectionForTable($this->tableTab);
        $connectionPool = GeneralUtility::makeInstance(ConnectionPool::class);
        /* @var QueryBuilder $queryBuilder */
        $queryBuilder = $connectionPool->getQueryBuilderForTable($this->tableTab);
        $queryBuilder->getRestrictions()->removeAll()->add(GeneralUtility::makeInstance(DeletedRestriction::class));
        try {
            // 1. Get all gridelements containers with Grid Layout "Tab Container"
            $gridElementsContainers = $queryBuilder
                ->select('*')
                ->from($this->tableTab)
                ->where(
                    $queryBuilder->expr()->eq('tx_gridelements_backend_layout', $this->gridElementBELayout)
                )
                ->orderBy('uid')
                ->execute()
                ->fetchAllAssociative();

            foreach ($gridElementsContainers as $container) {
                // and change their CType to "tab"
                $fields = [
                    'CType' => $this->targetCTypeTab,
                    'tx_gridelements_container' => 0,
                    'header' => 'Tab Container',
                    'header_layout' => 100,
                    'colPos' => $this->colPos
                ];

                $updatedRows = $connection->update(
                    $this->tableTab,
                    $fields,
                    ['uid' => $container['uid']]
                );

                if ($updatedRows > 0) {
                    // Get all children elements in the selected gridelements containers
                    $tabItems = $queryBuilder
                        ->select('*')
                        ->from($this->tableTab)
                        ->where(
                            $queryBuilder->expr()->eq('tx_gridelements_container', $container['uid'])
                        )
                        ->orderBy('uid')
                        ->execute();

                    foreach ($tabItems as $item) {
                        // 2. Add a new content element for each of the container's children
                        $queryBuilderTabItem = $connectionPool->getQueryBuilderForTable($this->targetTableTabItem);
                        $insertSuccessful = $queryBuilderTabItem
                            ->insert($this->targetTableTabItem)
                            ->values([
                                'pid' => $item['pid'],
                                'tt_content' => $item['tx_gridelements_container'],
                                'header' => $item['header'],
                                'bodytext' => $item['bodytext'],
                                'tstamp' => $GLOBALS['EXEC_TIME'],
                                'crdate' => $GLOBALS['EXEC_TIME'],
                                'mediaorient' => 'right',
                                $this->targetFieldNameImage => $item[$this->sourceFieldNameImage]

                            ])
                            ->execute();

                        if ($insertSuccessful) {
                            // Migrate existing images
                            $newItemUid = $queryBuilder->getConnection()->lastInsertId();
                            $fileReferenceQueryBuilder = $connectionPool->getQueryBuilderForTable('sys_file_reference');
                            $fileReferenceQueryBuilder
                                ->update('sys_file_reference')
                                ->where(
                                    $queryBuilderTabItem->expr()->andX(
                                        $queryBuilderTabItem->expr()->eq(
                                            'fieldname',
                                            $queryBuilderTabItem->quote($this->sourceFieldNameImage)
                                        ),
                                        $queryBuilderTabItem->expr()->eq('uid_foreign', $item['uid']),
                                        $queryBuilderTabItem->expr()->eq(
                                            'tablenames',
                                            $queryBuilder->quote($this->tableTab)
                                        )
                                    )
                                )
                                ->set('uid_foreign', $newItemUid)
                                ->set('tablenames', $this->targetTableTabItem)
                                ->set('fieldname', $this->targetFieldNameImage)
                                ->execute();
                        }
                    }

                    // Delete old tab items
                    $queryBuilderTabItemsOld = $connectionPool->getQueryBuilderForTable($this->tableTab);
                    $queryBuilderTabItemsOld
                        ->delete($this->tableTab)
                        ->where(
                            $queryBuilderTabItemsOld->expr()->eq('tx_gridelements_container', $container['uid'])
                        )
                        ->execute();
                }
            }
        } catch (Exception $e) {
            throw new RuntimeException(
                'Database query failed. Error was: ' . $e->getMessage(),
                1605857008
            );
        }
    }

    /**
     * Is an update necessary?
     *
     * Is used to determine whether a wizard needs to be run.
     * Check if data for migration exists.
     *
     * @return bool
     */
    public function updateNecessary(): bool
    {
        $updateNeeded = false;
        if ($this->checkIfWizardIsRequired()) {
            $updateNeeded = true;
        }

        return $updateNeeded;
    }

    /**
     * Returns an array of class names of prerequisite classes
     *
     * @return string[]
     */
    public function getPrerequisites(): array
    {
        return [];
    }

    /**
     * Check if there are gridelements containers with matching Grid Layout.
     *
     * @return bool
     * @throws InvalidArgumentException
     */
    protected function checkIfWizardIsRequired(): bool
    {
        $connectionPool = GeneralUtility::makeInstance(ConnectionPool::class);
        $queryBuilder = $connectionPool->getQueryBuilderForTable($this->tableTab);
        $queryBuilder->getRestrictions()->removeAll()->add(GeneralUtility::makeInstance(DeletedRestriction::class));

        $numberOfEntries = $queryBuilder
            ->count('uid')
            ->from($this->tableTab)
            ->where(
                $queryBuilder->expr()->eq('tx_gridelements_backend_layout', $this->gridElementBELayout)
            )
            ->execute()
            ->fetchOne();

        return $numberOfEntries > 0;
    }
}

Dieser Upgrade Wizard ist eine praktische Blaupause, die ihr an euer Projekt anpassen könnt. Etwas Erfahrung mit dem TYPO3 QueryBuilder ist von Vorteil; es bietet sich aber auch eine gute Gelegenheit zur Einarbeitung.

Wir wünschen euch viel Erfolg beim Ausprobieren! Habt ihr noch Fragen zum Thema?
